Ordering information
F.5 Spare parts and other hardware
S7-200 SMART
System Manual, 09/2015, A5E03822230-AC
707
Table F- 1 Terminal block spare kits
If you have
S7-200 SMART module (article number)
Use this terminal block spare kit (4/pk)
Terminal block article number
Terminal block description
CPU SR20, AC/DC/Relay (6ES7288-1SR20-0AA0)
6ES7292-1AH30-0XA0
8 pin, tin-plated
6ES7292-1AH40-0XA0
8 pin, tin-plated, keyed
6ES7292-1AM30-0XA0 12 pin, tin-plated
CPU ST20, DC/DC/DC (6ES7288-1ST20-0AA0)
6ES7292-1AH30-0XA0
8 pin, tin-plated
6ES7292-1AM30-0XA0
12 pin, tin-plated
CPU SR30, AC/DC/Relay (6ES7288-1SR30-0AA0)
6ES7292-1AH30-0XA0
8 pin, tin-plated
6ES7292-1AH40-0XA0
8 pin, tin-plated, keyed
6ES7292-1AP30-0XA0
14 pin, tin-plated
6ES7292-1AK30-0XA0
10 pin, tin-plated
CPU ST30, DC/DC/DC (6ES7288-1ST30-0AA0)
6ES7292-1AH30-0XA0
8 pin, tin-plated
6ES7292-1AP30-0XA0
14 pin, tin-plated
6ES7292-1AK30-0XA0
10 pin, tin-plated
CPU ST40, DC/DC/DC (6ES7288-1ST40-0AA0)
6ES7292-1AH30-0XA0
8 pin, tin-plated
6ES7292-1AV30-0XA0
20 pin, tin-plated
6ES7 292-1AL30-0XA0
11 pin, tin-plated
CPU SR40, AC/DC/Relay (6ES7288-1SR40-0AA0)
6ES7292-1AV30-0XA0
20 pin, tin-plated
6ES7292-1AV40-0XA0
20 pin, tin-plated, keyed
6ES7292-1AM30-0XA0
12 pin, tin-plated
CPU CR40, AC/DC/Relay (6ES7288-1CR40-0AA0)
6ES7292-1AH30-0XA0
8 pin, tin-plated
6ES7292-1AV30-0XA0
20 pin, tin-plated
6ES7292-1AL30-0XA0
11 pin, tin-plated
6ES7292-1AL40-0XA0
11 pin, tin-plated, keyed
CPU ST60, DC/DC/DC (6ES7288-1ST60-0AA0)
6ES7292-1AV30-0XA0
20 pin, tin-plated
6ES7292-1AM30-0XA0 12 pin, tin-plated
CPU SR60, AC/DC/Relay (6ES7288-1SR60-0AA0)
6ES7292-1AV30-0XA0
20 pin, tin-plated
6ES7292-1AV40-0XA0 20 pin, tin-plated, keyed
6ES7292-1AM30-0XA0
12 pin, tin-plated
CPU CR60, AC/DC/Relay (6ES7 288-1CR60-0AA0)
6ES7292-1AV30-0XA0
20 pin, tin-plated
6ES7292-1AV40-0XA0
20 pin, tin-plated, keyed
6ES7292-1AM30-0XA
12 pin, tin-plated 0
EM Digital 8 x Inputs (EM DE08) (6ES7288-2DE08-
0AA0)
6ES7292-1AG30-0XA0 7 pin, tin-plated
EM Digital 8 x Outputs (EM DT08) (6ES7288-2DT08-
0AA0)
6ES7292-1AG30-0XA0 7 pin, tin-plated
EM Digital 8 x Outputs Relay (EM DR08) (6ES7288-
2DR08-0AA0)
6ES7292-1AG30-0XA0
7 pin, tin-plated
6ES7292-1AG40-0XA0
7 pin, tin-plated, keyed-right
EM Digital 8 x Inputs / Digital 8 x Outputs (EM DT16)
(6ES7288-2DT16-0AA0)
6ES7292-1AG30-0XA0 7 pin, tin-plated

Siemens Simatic S7 Series Specifications

General

CPU	Varies by model (e.g., S7-300, S7-400, S7-1200, S7-1500)
Communication Interfaces	PROFIBUS, PROFINET, Ethernet, MPI
Programming	TIA Portal, STEP 7
Programming Languages	LAD, FBD, STL, SCL, GRAPH
I/O Modules	Digital, Analog, Specialty modules available
Operating Temperature	0°C to 60°C (standard models)
Mounting	DIN rail mounting
Operating Voltage	24V DC or 120/230V AC (varies by model)
Protection Class	IP20 (standard models)
Memory	Varies depending on the S7 model. Includes work memory (RAM) for program execution, load memory (EEPROM or Flash) for program storage, and system memory for operating system functions. Memory sizes range from kilobytes to megabytes.
