Technical specifications
A.10 EM DP01 PROFIBUS DP module
S7-200 SMART
648 System Manual, 09/2015, A5E03822230-AC
A.10
EM DP01 PROFIBUS DP module
Table A- 147 General specifications
Technical data
EM DP01 PROFIBUS DP
Article number
6ES7 288-7DP01-0AA0
Dimensions W x H x D (mm) 70 x 100 x 81
Weight
176.2 g
Power dissipation 1.5 W (no load)
V DC requirements
+5 V DC (SM Bus)
150 mA (no load)
+24 V DC
See below
Table A- 148 EM features
Technical data
EM DP01 PROFIBUS DP module
Number of ports (limited pow-
er)
1
Electrical interface
RS485
PROFIBUS DP / MPI baud
rates (set automatically)
9.6, 19.2, 45.45, 93.75, 187.5, and 500 kbaud; 1, 1.5, 3.6, and 12 Mbaud
Protocols
PROFIBUS DP slave and MPI slave
Cable length
Up to 93.7 kbaud
1200 m
187.5 kbaud
1000 m
500 kbaud
400 m
1 to 1.5 Mbaud
200 m
3 to 12 Mbaud
100 m
Network capabilities
Station address settings
0 to 99 (set by rotary switches)
Maximum stations per seg-
ment
32
Maximum stations per net-
work
126, up to 99 EM DP01 stations
MPI connections
6 total, 2 reserved (1 for PG and 1 for OP)

Siemens Simatic S7 Series Specifications

General

CPU	Varies by model (e.g., S7-300, S7-400, S7-1200, S7-1500)
Communication Interfaces	PROFIBUS, PROFINET, Ethernet, MPI
Programming	TIA Portal, STEP 7
Programming Languages	LAD, FBD, STL, SCL, GRAPH
I/O Modules	Digital, Analog, Specialty modules available
Operating Temperature	0°C to 60°C (standard models)
Mounting	DIN rail mounting
Operating Voltage	24V DC or 120/230V AC (varies by model)
Protection Class	IP20 (standard models)
Memory	Varies depending on the S7 model. Includes work memory (RAM) for program execution, load memory (EEPROM or Flash) for program storage, and system memory for operating system functions. Memory sizes range from kilobytes to megabytes.
