Technical specifications
A.7 Analog signal boards
S7-200 SMART
642 System Manual, 09/2015, A5E03822230-AC
Table A- 134 Connector pin locations for SB AE01 Analog Input 1 x Input (6ES7 288-5AE01-0AA0)
Pin
X19
1
No connection
2 No connection
3
AI R
4 AI 0+
5
AI 0+
6
AI 0-
A.7.2
SB AQ01 analog output specifications
Table A- 135 General specifications
Technical data
SB Analog 1 x Output (SB AQ01)
Article number
6ES7 288-5AQ01-0AA0
Dimensions W x H x D (mm)
35 x 52.2 x 16
Weight
17.4 grams
Power dissipation
1.5 W
Current consumption (5 V DC)
15 mA
Current consumption (24 V DC)
40 mA (no load)
Table A- 136 Analog outputs
Technical data
SB Analog 1 x Output (SB AQ01)
Number of outputs
1
Type
Voltage or current
Range
±10 V, 0 to 20 mA
Resolution Voltage: 11 bits + sign
Current: 11 bits
Full scale range (data word)
Refer to the output ranges for
voltage and current.
-27,648 to 27,648 (-10 V to 10 V)
0 to 27,648 (0 to 20 mA)
Accuracy (25°C / 0 to 55°C)
±0.5% / ±1%
Settling time (95% of new value) Voltage: 300 μs (R), 750 μs (1 μF)
Current: 600 μs (1mH), 2 ms (10 mH)
Load impedance Voltage: ≥ 1000 ohms
Current: ≤ 600 ohms
Output behavior in STOP
Last value, substitute value (default value 0)
Isolation (field side to logic)
None
Cable length (max.), in meters
10 m twisted and shielded
