Siemens Simatic S7 Series System Manual

S7-200 SMART
System Manual, 09/2015, A5E03822230-AC
705
Ordering information
F
F.1
CPU modules
CPU models
Article number
CPU SR20, AC/DC/Relay
6ES7 288-1SR20-0AA0
CPU ST20, DC/DC/DC
6ES7 288-1ST20-0AA0
CPU SR30, AC/DC/Relay 6ES7 288-1SR30-0AA0
CPU ST30, DC/DC/DC
6ES7 288-1ST30-0AA0
CPU ST40, DC/DC/DC 6ES7 288-1ST40-0AA0
CPU SR40, AC/DC/Relay
6ES7 288-1SR40-0AA0
CPU CR40, AC/DC/Relay
6ES7 288-1CR40-0AA0
CPU SR60, AC/DC/Relay
6ES7 288-1SR60-0AA0
CPU ST60, DC/DC/DC
6ES7 288-1ST60-0AA0
CPU CR60, AC/DC/Relay
6ES7 288-1CR60-0AA0
F.2
Expansion modules (EMs) and signal boards (SBs)
Expansion modules and signal boards
Article number
EM Digital 8 x Inputs (EM DE08)
6ES7 288-2DE08-0AA0
EM Digital 8 x Outputs (EM DT08)
6ES7 288-2DT08-0AA0
EM Digital 8 x Outputs Relay (EM DR08)
6ES7 288-2DR08-0AA0
EM Digital 8 x Inputs / Digital 8 x Outputs (EM DT16)
6ES7 288-2DT16-0AA0
EM Digital 8 x Inputs/ Relay 8 x Outputs (EM DR16)
6ES7 288-2DR16-0AA0
EM Digital 16 x Inputs / Digital 16 x Outputs (EM DT32)
6ES7 288-2DT32-0AA0
EM Digital 16 x Inputs / Relay 16 x Outputs (EM DR32)
6ES7 288-2DR32-0AA0
EM Analog 4 x Inputs (EM AE04)
6ES7 288-3AE04-0AA0
EM Analog 2 x Outputs (EM AQ02)
6ES7 288-3AQ02-0AA0
EM Analog 4 x Outputs (EM AQ04)
6ES7 288-3AQ04-0AA0
EM Analog 8 x Inputs (EM AE08)
6ES7 288-3AE08-0AA0
EM Analog 2 x Inputs / Analog 1 x Outputs (EM AM03)
6ES7 288-3AM03-0AA0
EM Analog 4 x Inputs / Analog 2 x Outputs (EM AM06)
6ES7 288-3AM06-0AA0
EM RTD 2 x 16 bit (EM AR02) 6ES7 288-3AR02-0AA0
EM RTD 4 x 16 bit (EM AR04)
6ES7 288-3AR04-0AA0
EM TC 4 x 16 bit (EM AT04)
6ES7 288-3AT04-0AA0
EM DP01 PROFIBUS DP SMART (EM DP01)
6ES7 288-7PD01-0AA0

Siemens Simatic S7 Series Specifications

General

CPU	Varies by model (e.g., S7-300, S7-400, S7-1200, S7-1500)
Communication Interfaces	PROFIBUS, PROFINET, Ethernet, MPI
Programming	TIA Portal, STEP 7
Programming Languages	LAD, FBD, STL, SCL, GRAPH
I/O Modules	Digital, Analog, Specialty modules available
Operating Temperature	0°C to 60°C (standard models)
Mounting	DIN rail mounting
Operating Voltage	24V DC or 120/230V AC (varies by model)
Protection Class	IP20 (standard models)
Memory	Varies depending on the S7 model. Includes work memory (RAM) for program execution, load memory (EEPROM or Flash) for program storage, and system memory for operating system functions. Memory sizes range from kilobytes to megabytes.
