Page #580 background image
Technical specifications
A.2 S7-200 SMART CPUs
S7-200 SMART
580 System Manual, 09/2015, A5E03822230-AC
Table A- 27 Sensor power
Technical data
CPU ST30 DC/DC/DC
CPU SR30 AC/DC/Relay
Voltage range
20.4 to 28.8 V DC
20.4 to 28.8 V DC
Output current rating (max.) 300 mA (short circuit protected) 300 mA (short circuit protected)
Maximum ripple noise (<10
MHz)
< 1 V peak to peak < 1 V peak to peak
Isolation (CPU logic to sensor
power)
Not isolated Not isolated
A.2.2.2
Digital inputs and outputs
Table A- 28 Digital inputs
Technical data
CPU ST30 DC/DC/DC
CPU SR30 AC/DC/Relay
Number of inputs
18
18
Type Sink/Source (IEC Type 1 sink, except
I0.0 to I0.3, I0.6 to I0.7)
Sink/Source (IEC Type 1 sink)
Rated voltage
24 V DC at 4 ma, nominal
24 V DC at 4 mA, nominal
Continuous permissible voltage
30 V DC, max
30 V DC, max.
Surge voltage
35 V DC for 0.5 sec.
35 V DC for 0.5 sec.
Logic 1 signal (min.) I0.0 to I0.3, I0.6 to I0.7: 4 V DC at 8 mA
Other inputs: 15 V DC at 2.5 mA
15 V DC at 2.5 mA
Logic 0 signal (max.) I0.0 to I0.3, I0.6 to I0.7: 1 V DC at 1 mA
Other inputs: 5 V DC at 1 mA
5 V DC at 1 mA
Isolation (field side to logic)
500 V AC for 1 minute
500 V AC for 1 minute
Isolation groups
1
1
Filter times Individually selectable on each channel
(points I0.0 to I1.5):
μs: 0.2, 0.4, 0.8, 1.6, 3.2, 6.4, 12.8
ms: 0.2, 0.4, 0.8, 1.6, 3.2, 6.4, 12.8
Individually selectable on each channel
(points I0.0 to I1.5):
μs: 0.2, 0.4, 0.8, 1.6, 3.2, 6.4, 12.8
ms: 0.2, 0.4, 0.8, 1.6, 3.2, 6.4, 12.8
Individually selectable on each channel
(points I1.6 and greater):
ms: 0, 6.4, 12.8
Individually selectable on each channel
(points I1.6 and greater):
ms: 0, 6.4, 12.8
HSC clock input rates (max.)
(Logic 1 Level = 15 to 26 V DC)
4 HSC at 200 KHz for single phase
2 HSC at 100 KHz for A/B phase
4 HSC at 200 KHz for single phase
2 HSC at 100 KHz for A/B phase
Number of inputs on simultane-
ously
18 18
Cable length (max.), in meters
I0.0 to I0.3:
Shielded (only):
500 m normal (low-speed) inputs
50 m HSC (high-speed) inputs
All inputs:
Shielded: 500 m normal inputs,
50 m HSC inputs
Unshielded: 300 m normal inputs
I0.6 to I0.7:
Shielded (only): 500 m normal inputs
