Technical specifications
A.4 Analog inputs and outputs expansion modules (EMs)
S7-200 SMART
616 System Manual, 09/2015, A5E03822230-AC
Table A- 88 Connector pin locations for EM AE08 Analog 8 x Inputs (6ES7 288-3AE08-0AA0)
Pin
X10 (gold)
X11 (gold)
X12 (gold)
X13 (gold)
1
L+ / 24 V DC
No connection
No connection
No connection
2 M / 24 V DC No connection No connection No connection
3
Functional Earth
No connection
No connection
No connection
4 AI 0+ AI 2+ AI 4+ AI 6+
5
AI 0-
AI 2-
AI 4-
AI 6-
6
AI 1+
AI 3+
AI 5+
AI 7+
7
AI 1-
AI 3-
AI 5-
AI 7-
A.4.2
EM AQ02 and EM AQ04 analog output module specifications
Table A- 89 General specifications
Technical data
EM Analog 2 x outputs (EM AQ02)
EM Analog 4 x outputs (EM AQ04)
Article number
6ES7 288-3AQ02-0AA0
6ES7 288-3AQ04-0AA0
Dimensions W x H x D (mm)
45 x 100 x 81
45 x 100 x 81
Weight
147.1 grams
170.5 grams
Power dissipation
1.5 W (no load)
2.1 W (no load)
Current consumption (SM Bus)
60 mA
60 mA
Current consumption (24 V DC)
50 mA (no load)
75 mA (no load
Table A- 90 Analog outputs
Technical data
EM Analog 2 x outputs (EM AQ02)
EM Analog 4 x outputs (EM AQ04)
Number of outputs
2
4
Type
Voltage or current
Voltage or current
Range
±10 V or 0 to 20 mA
±10 V or 0 to 20 mA
Resolution Voltage mode: 11 bits + sign bit
Current mode: 11 bits
Voltage mode: 11 bits + sign bit
Current mode: 11 bits
Full scale range (data word) Voltage: -27,648 to 27,648
Current: 0 to 27,648
Voltage: -27,648 to 27,648
Current: 0 to 27,648
(Refer to the output ranges for voltage and
current (Page 625).)
Accuracy (25°C / 0 to 55°C) ±0.5% / ±1.0% of full scale ±0.5% / ±1.0% of full scale
Settling time (95% of new value) Voltage: 300 μs (R), 750 μ (R), 750 μs (1
μF)
Current: 600 μs (1 mH), 2 ms (10 mH)
Voltage: 300 μs (R), 750 μ (R), 750 μs (1
μF)
Current: 600 μs (1 mH), 2 ms (10 mH)
Load impedance Voltage: ≥ 1000 Ω
Current: ≤ 500 Ω
Voltage: ≥ 1000 Ω
Current: ≤ 600 Ω
Output behavior in STOP Last value or substitute value (default
value 0)
Last value or substitute value (default value
0)

Siemens Simatic S7 Series Specifications

General

CPU	Varies by model (e.g., S7-300, S7-400, S7-1200, S7-1500)
Communication Interfaces	PROFIBUS, PROFINET, Ethernet, MPI
Programming	TIA Portal, STEP 7
Programming Languages	LAD, FBD, STL, SCL, GRAPH
I/O Modules	Digital, Analog, Specialty modules available
Operating Temperature	0°C to 60°C (standard models)
Mounting	DIN rail mounting
Operating Voltage	24V DC or 120/230V AC (varies by model)
Protection Class	IP20 (standard models)
Memory	Varies depending on the S7 model. Includes work memory (RAM) for program execution, load memory (EEPROM or Flash) for program storage, and system memory for operating system functions. Memory sizes range from kilobytes to megabytes.
