Ordering information
F.6 Human Machine Interface devices
S7-200 SMART
708 System Manual, 09/2015, A5E03822230-AC
If you have
S7-200 SMART module (article number)
Use this terminal block spare kit (4/pk)
Terminal block article number
Terminal block description
EM Digital 8 x Inputs/ Relay 8 x Outputs (EM DR16)
(6ES7288-2DR16-0AA0)
7 pin, tin-plated, keyed-right
EM Digital 16 x Inputs / Digital 16 x Outputs (EM DT32)
6ES7292-1AL30-0XA0 11 pin, tin-plated
EM Digital 16 x Inputs / Relay 16 x Outputs (EM DR32)
(6ES7288-2DR32-0AA0)
11 pin, tin-plated, keyed
EM Analog 4 x Inputs (EM AE04) (6ES7288-3AE04-
6ES7292-1BG30-0XA0 7 pin, gold-plated
EM Analog 8 x Inputs (EM AE08) (6ES7288-3AE08-
6ES7292-1BG30-0XA0 7 pin, gold-plated
EM Analog 2 x Outputs (EM AQ02) (6ES7288-3AQ02-
6ES7292-1BG30-0XA0 7 pin, gold-plated
EM Analog 4 x Outputs (EM AQ04) (6ES7288-3AQ04-
6ES7292-1BG30-0XA0 7 pin, gold-plated
EM Analog 2 x Inputs / Analog 1 x Outputs (EM AM03)
6ES7292-1BG30-0XA0 7 pin, gold-plated
EM Analog 4 x Inputs / Analog 2 x Outputs (EM AM06)
6ES7292-1BG30-0XA0 7 pin, gold-plated
EM RTD 2 x 16 bit (EM AR02) (6ES7288-3AR02-0AA0)
EM RTD 4 x 16 bit (EM AR04) (6ES7288-3AR04-0AA0)
EM TC 4 x 16 bit (EM AT04) (6ES7288-3AT04-0AA0)
EM Profibus DP SMART (EM DP01) (6ES7288-7DP01-
6ES7292-1BG30-0XA0 7 pin, gold-plated
Human Machine Interface devices
Human Machine Interface device
SMART LINE 1000 IE 6AV6648-0BE11-3AX0
TD 400C TEXT DISPLAY, 4 LINES
1
TD400C Blank faceplate material, A4 size (10 sheets/package)
1
: Includes one blank faceplate overlay for customization. For additional blank faceplate
overlays, order the blank faceplate material for your TD device
