Siemens Simatic S7 Series System Manual

Special memory (SM) and system symbol names
D.28 SMB1100-SMB1399: EM (expansion module) hardware/firmware ID
S7-200 SMART
System Manual, 09/2015, A5E03822230-AC
689
D.28
SMB1100-SMB1399: EM (expansion module) hardware/firmware ID
Expansion module information is written to special memory after a power-up or warm restart
transition. The SMB1100-SMB1399 section of special memory is read-only.
SM addresses for slot 0
Description
SMW1100 EM bus Slot 0 vendor ID: Set to 0x002A if a Siemens EM is present and 0x0000 if no EM is
present
SMB1102 to SMB1121 EM bus Slot 0 order ID (MLFB): ASCII characters, left-justified in field, padded with spaces
SMB1122 to SMB1137
EM bus slot 0 serial number: ASCII characters, left-justified in field, padded with spaces
SMW1138 EM bus slot 0 hardware version: represents the hardware E-stand; range = 0x0001 to 0xFFFD
(0x0000, 0xFFFE, and 0xFFFF are reserved values)
SMD1140 EM bus slot 0 firmware version: Byte 0 is ASCII ‘V’, byte 1=functional version, byte 2= minor
change version, byte 3=bug fix version (range of bytes 1-3 = 0x00 to 0xFF)
SMW1144
EM bus slot 0 firmware version counter (range 0x0000 to 0x00FF)
SMW1146
Reserved, always 0x0000
SMW1148
EM bus slot 0 device type: I/O=0x0003, communications=0x0004, all other values reserved
SM addresses for slot 1
Description
SMW1150 EM bus slot 1 vendor ID: Set to 0x002A if a Siemens EM is present and 0x0000 if no EM is
present
SMB1152 to SMB1171
EM bus slot 1 order ID (MLFB): ASCII characters, left-justified in field, padded with spaces
SMB1172 to SMB1187
EM bus slot 1: serial number: ASCII characters, left-justified in field, padded with spaces
SMW1188 EM bus slot 1 hardware version: Represents the hardware E-stand; range=0x0001 to 0xFFFD
(0x0000, 0xFFFE, and 0xFFFF are reserved values)
SMD1190 EM bus slot 1 firmware version: Byte 0 is ASCII ‘V’; byte 1=functional version, byte 2=minor
change version, byte 3=bug fix version (range of bytes 1-3 = 0x00 to 0xFF)
SMW1194
EM bus slot 1 firmware version counter (range 0x0000 to 0x00FF)
SMW1196
Reserved, always 0x0000
SMW1198
EM bus slot 1 device type: I/O=0x0003, communications=0x0004, all other values reserved
SM addresses for slot 2
Description
SMW1200 EM bus slot 2 vendor ID: Set to 0x002A if a Siemens EM is present and 0x0000 if no EM is
present
SMB1202 to SMB1221
EM bus slot 2 order ID (MLFB): ASCII characters, left-justified in field, padded with spaces
SMB1222 to SMB1237
EM bus slot 2 serial number: ASCII characters, left-justified in field, padded with spaces
SMW1238 EM bus slot 2 hardware version: Represents the hardware E-stand; range = 0x0001 to
0xFFFD (0x0000, 0xFFFE, and 0xFFFF are reserved values)
SMD1240 EM bus slot 2 firmware version: Byte 0 is ASCII ‘V’; byte 1=functional version, byte 2=minor
change version, byte 3 = bug fix version (range of bytes 1-3=0x00 to 0xFF)
SMW1244
EM bus slot 2 firmware version counter (range 0x0000 to 0x00FF)
SMW1246
Reserved, always 0x0000
SMW1248
EM bus slot 2 device type: I/O=0x0003, communications=0x0004, all other values reserved
