Siemens Simatic S7 Series System Manual

S7-200 SMART
System Manual, 09/2015, A5E03822230-AC
693
References
E
E.1
Often-used special memory bits
The complete list of pre-defined special memory program symbols is available to your
project, in the System Symbol table.
Table E- 1 Often-used special memory bits
SM address
System symbol name
Description
SM0.0
Always_On
Always ON
SM0.1
First_Scan_On
ON for the first scan cycle only
SM0.2 Retentive_Lost ON for one scan cycle if retentive data is lost
SM0.3
RUN_Power_Up
ON for 1 scan cycle when RUN mode is entered from a power-up condition
SM0.4 Clock_60s Clock pulse that is ON for 30 s, OFF for 30 s, for a cycle time of 1 min.
SM0.5
Clock_1s
Clock pulse that is ON for 0.5 s, OFF for 0.5 s, for a cycle time of 1 s.
SM0.6
Clock_Scan
Scan cycle clock which is ON for one scan cycle and OFF for the next scan cycle
SM0.7 RTC_Lost This bit is turned ON for one scan cycle, if the time on the real time clock device
was reset or lost at power-up (resulting in system time lost). This bit can be used
as either an error memory bit, or to invoke a special start-up sequence.
SM1.0 Result_0 Set to 1 by the execution of certain instructions when the result of the operation
= 0
SM1.1 Overflow_Illegal Set to 1 by the execution of certain instructions on overflow or illegal numeric
value
SM1.2
Neg_Result
Set to 1 when a math operation produces a negative result
SM1.3
Divide_By_0
Set to 1 when an attempt is made to divide by zero
SM1.4
Table_Overflow
Set to 1 when the Add to Table instruction attempts to overfill the table
SM1.5
Table_Empty
Set to 1 when a LIFO or FIFO instruction attempts to read from an empty table
SM1.6
Not_BCD
Set to 1 when an attempt is made to convert a non-BCD value to a binary value
SM1.7
Not_Hex
Set to 1 when an ASCII value cannot be converted to a valid hexadecimal value
