Special memory (SM) and system symbol names
D.26 SMB1000-SMB1049: CPU hardware/firmware ID
S7-200 SMART
688 System Manual, 09/2015, A5E03822230-AC
D.26
SMB1000-SMB1049: CPU hardware/firmware ID
This CPU information is written to special memory after a power-up or warm restart
transition. The SMB1000-SMB1049 section of special memory is read-only.
SM address
Description
SMW1000
CPU vendor ID: (always 0x002A)
SMB1002 to SMB1021 CPU order ID (MLFB): ASCII characters, left-justified in field, padded with spaces
SMB1022 to SMB1037
CPU serial number: ASCII characters, left-justified in field, padded with spaces
SMW1038 CPU hardware version: Represents the hardware E-stand; range = 0x0001 to 0xFFFD
(0x0000, 0xFFFE, and 0xFFFF are reserved values)
SMD1040 CPU firmware version: Byte 0 is ASCII ‘V’; byte 1=functional version; byte 2=minor change
version; byte 3=bug fix version (range of bytes 1-3 = 0x00 to 0xFF)
SMW1044
CPU firmware version counter (range 0x0000 to 0x00FF)
SMW1046
Reserved: Always 0x0000
SMW1048
CPU device type: Always 0x0001
D.27
SMB1050-SMB1099: SB (signal board) hardware/firmware ID
This signal board information is written to special memory after a power-up or warm restart
transition. The SMB1050-SMB1099 section of special memory is read-only.
SM address
Description
SMW1050 Signal board vendor ID: Set to 0x002A if a Siemens SB is present and 0x0000 if no SB is pre-
sent
SMB1052 to SMB1071
Signal board order ID (MLFB): ASCII characters, left-justified in field, padded with spaces
SMB1072 to SMB1087
Signal board serial number: ASCII characters, left-justified in field, padded with spaces
SMW1088 Signal board hardware version: Represents the hardware E-stand; range=0x0001 to 0xFFFD,
(0x0000, 0xFFFE, and 0xFFFF are reserved values)
SMD1090 Signal board firmware version; Byte 0 is ASCII ‘V’; byte 1=functional version; byte 2=minor
change version; byte 3=bug fix version (range of bytes 1-3 = 0x00 to 0xFF)
SMW1094
Signal board firmware version counter (range 0x0000 to 0x00FF)
SMW1096
Reserved, always 0x0000
SMW1098 Signal board device type: I/O=0x0003, communications=0x0004, all other values reserved
