Program instructions
7.3 Communication
S7-200 SMART
System Manual, 09/2015, A5E03822230-AC
173
Table 7- 4 Error codes for the GET and PUT instructions TABLE parameter
Code
Definition
0
No error
1 Illegal parameter in the PUT/GET table:
• Local area is not I, Q, M, or V
• Local area is not large enough for the data length requested
• Data length is zero or greater than 222 bytes for a GET or greater than 212 bytes for a PUT
• Remote area is not I, Q, M, or V
• Remote IP address is illegal (0.0.0.0)
• Remote IP address is a broadcast address or a multicast address
• Remote IP address is the same as the Local IP address
• Remote IP address is on a different subnet
2
Too many PUT/GET instructions are currently active (only 16 allowed)
3
No connection available. All connections are currently active with outstanding requests
4 Error returned from remote CPU:
• Too much data was requested or sent
• Writing to Q memory is not allowed in STOP mode
• Memory area is write-protected (see SDB configuration)
5 No connection available to the remote CPU:
• Remote CPU does not have an available server connection
• Connection to remote CPU was lost (CPU powered off, physical disconnect)
6 to 9,
A to F
Not used (Reserved for future use)
