Program instructions
7.11 Logical operations
S7-200 SMART
System Manual, 09/2015, A5E03822230-AC
295
Example: AND, OR, and Exclusive OR instructions
LAD
STL
Network 1
LD I4.0
ANDW AC1, AC0
ORW AC1, VW100
XORW AC1, AC0
