Table 9- 12 USS_RPM_x parameter descriptions
Parameter
Description
XMT_REQ
(transmit re-
quest)
When ON, a USS_RPM_x request is transmitted to the drive on every scan.
Drive Address of the drive to which the USS_RPM_x command is to be sent. Valid ad-
dresses of individual drives are 0 to 31.
Param
Parameter number
Index
Index value of the parameter that is to be read
DB_Ptr The address of a 16-byte buffer must be supplied to the "DB_Ptr" input. This buffer
is used by the USS_RPM_x instruction to store the results of the command issued
to the drive.
Done
Turned on when the USS_RPM_x instruction completes
Error This output byte contains the result of executing the instruction. The USS protocol
execution error codes (Page 428) define the error conditions that could result from
executing the instruction.
Value
Parameter value returned
When the USS_RPM_x instruction completes, the "Done" output is turned on and the "Error"
output byte and the "Value" output contain the results of executing the instruction. The
"Error" and "Value" outputs are not valid until the "Done" output turns on.
