Open loop motion control
12.1 Using the PWM output
S7-200 SMART
484 System Manual, 09/2015, A5E03822230-AC
Table 12- 1 Parameters for the PWMx_RUN subroutine
IW, QW, VW, MW, SMW, SW, T, C, LW, AC, AIW, *VD, *AC, *LD, Constant
Error Byte IB, QB, VB, MBV, SMB, LB, AC, *VD, *AC, *LD, Constant
The Cycle input is a word value that defines the cycle time for the pulse width modulation
(PWM) output. The allowed range is from 2 to 65535 when milliseconds is the time base and
10 to 65535 when microseconds is the time base.
The Pulse input is a word value that defines the pulse width (Duty Cycle) for the PWM
output. The allowed range of values is from 0 to 65535 units of the time base (microseconds
or milliseconds) that was specified within the PWM wizard.
The Error is a byte value returned by the PWMx_RUN subroutine that indicates the result of
execution. See the following table for a description of the possible error codes.
Table 12- 2 PWMx_RUN instruction error codes
No error, normal completion
131 Pulse generator already in use by another PWM or by a motion axis, or illegal time base change
