Technical specifications
A.1 General specifications
S7-200 SMART
566 System Manual, 09/2015, A5E03822230-AC
The S7-200 SMART automation system is designed for use in industrial environments.
Table A- 1 Industrial environments
Noise emission requirements
Noise immunity requirements
Electromagnetic compatibility
Electromagnetic Compatibility (EMC) is the ability of an electrical device to operate as
intended in an electromagnetic environment and to operate without emitting levels of
electromagnetic interference (EMI) that may disturb other electrical devices in the vicinity.
Table A- 2 Immunity per EN 61000-6-2
Electromagnetic compatibility - Immunity per EN 61000-6-2
EN 61000-4-2
Electrostatic discharge
±8 kV air discharge to all surfaces
±4 kV contact discharge to exposed conductive surfaces
EN 61000-4-3
Radiated, radio-frequency, electromagnet-
80 to 1000 MHz, 10 V/m, 80% AM at 1 kHz
1.4 to 2.0 GHz, 3 V/m, 80% AM a 1 kHz
2.0 to 2.7 GHz, 1 V/m, 80% AM at 1 kHz
EN 61000-4-4
2 kV, 5 kHz with coupling network to AC and DC system power
2 kV, 5 kHz with coupling clamp to I/O
EN 6100-4-5
Surge immunity
AC systems - 2 kV common mode, 1kV differential mode
DC systems - 2 kV common mode, 1kV differential mode
For DC systems (I/O signals, DC power systems) external protection is re-
EN 61000-4-6
Immunity to conducted disturbances
150 kHz to 80 MHz, 10 V RMS, 80% AM at 1kHz
EN 61000-4-11
AC systems
0% for 1 cycle, 40% for 12 cycles and 70% for 30 cycles at 60 Hz
Table A- 3 Conducted and radiated emissions per EN 61000-6-4
Electromagnetic compatibility - Conducted and radiated emissions per EN 61000-6-4
Conducted Emissions
EN 55011, Class A, Group 1
<79dB (μV) quasi-peak; <66 dB (μV) average
<73dB (μV) quasi-peak; <60 dB (μV) average
Radiated Emissions
EN 55011, Class A, Group 1
<40dB (μV/m) quasi-peak; measured at 10m
<47dB (μV/m) quasi-peak; measured at 10m
