Technical specifications
A.1 General specifications
S7-200 SMART
568 System Manual, 09/2015, A5E03822230-AC
Contamination level/overvoltage category according to IEC 61131-2
● Pollution degree 2
● Overvoltage category: II
Protection class in accordance with IEC 61131-2
● Protection Class II according to EN 61131-2 (Protective conductor not required)
Degree of protection IP20
● IP20 Mechanical Protection, EN 60529
● Protects against finger contact with high voltage as tested by standard probe. External
protection required for dust, dirt, water and foreign objects of < 12.5mm in diameter.
Table A- 7 Rated voltages
120/240 V AC 85 V AC to 264 V AC, 47 to 63 Hz
Note
When a mechanical contact turns on output power to the S7
-200 SMART CPU, or any
digital
expansion module, it sends a "1" signal to the digital outputs for approximately 150
microseconds. This could cause unexpected machine or process operation which could
result in death or serious injury to personnel and/or damage to equipment. You must plan for
this, especially if you are using devices which respond to short duration pulses.
