PLC concepts
4.2 Accessing data
S7-200 SMART
64 System Manual, 09/2015, A5E03822230-AC
HC (high-speed counter)
The high-speed counters count high-speed events independent of the CPU scan. High-
speed counters have a signed, 32-bit integer counting value (or current value). To access
the count value for the high-speed counter, you specify the address of the high-speed
counter, using the memory type (HC) and the counter number. The current value of the high-
speed counter is a read-only value and can be addressed only as a double word (32 bits).
Table 4- 10 Absolute addressing of HC memory
High-speed counter HC [high-speed counter number] HC1
AC (accumulators)
The accumulators are read/write devices that can be used like memory. For example, you
can use accumulators to pass parameters to and from subroutines and to store intermediate
values used in a calculation. The CPU provides four 32-bit accumulators (AC0, AC1, AC2,
and AC3). You can access the data in the accumulators as bytes, words, or double words.
The size of the data being accessed is determined by the instruction that is used to access
the accumulator. As shown in the following figure, you use the least significant 8 or 16 bits of
the value that is stored in the accumulator to access the accumulator as bytes or words. To
access the accumulator as a double word, you use all 32 bits.
For information about how to use the accumulators within interrupt subroutines, refer to the
Interrupt instructions (Page 282).
Table 4- 11 Absolute addressing of AC memory
Accumulator AC [accumulator number] AC0

Siemens Simatic S7 Series Specifications

General

CPU	Varies by model (e.g., S7-300, S7-400, S7-1200, S7-1500)
Communication Interfaces	PROFIBUS, PROFINET, Ethernet, MPI
Programming	TIA Portal, STEP 7
Programming Languages	LAD, FBD, STL, SCL, GRAPH
I/O Modules	Digital, Analog, Specialty modules available
Operating Temperature	0°C to 60°C (standard models)
Mounting	DIN rail mounting
Operating Voltage	24V DC or 120/230V AC (varies by model)
Protection Class	IP20 (standard models)
Memory	Varies depending on the S7 model. Includes work memory (RAM) for program execution, load memory (EEPROM or Flash) for program storage, and system memory for operating system functions. Memory sizes range from kilobytes to megabytes.
