CONVEYOR ENHANCEMENTS
Conveyor Wire Belt Set Up
2-9317-600-00-0 Aquastorm™ Series Options Guide 6-87
Diagram Figure 6–6 shows the wire belt feeding diagram:
Figure 6–6
Open Side
of Loop
Facing
Toward
Entrance
End
Closed
Loop Side
Toward
Exit End
Entrance
End
Exit End
Feed the Wire Belt from the top of the conveyor at the
entrance end toward the exit end of the system, then
around the underside of the conveyor, toward the entrance
end of the Optional Inlet Conveyor assembly.
To Next Page
