HURRICANE JETS™ AND PUMPS
Remove Lower Nozzle
2-9317-600-00-0 Aquastorm™ Series Options Guide 11-217
Photograph Figure 11–16 shows the steps to loosen and remove a quick release clamp.
Figure 11–17 shows the Hurricane Jet™ outer nozzle.
Figure 11–16
Figure 11–17
