BLOWER ENHANCEMENTS
Repair
16-310 Aquastorm™ Series Options Guide Rev. 1
16
Photograph Figure 16–4 shows the front Electrosonic™ airknife torque adjust mounting screw
locations.
Figure 16–4
Procedure Use the following steps to access the Electrosonic™ airknives:
1. Shut down Aquastorm™ system operation.
2. Ensure system power is Off.
3. Perform Lock Out/Tag Out steps. See Lock-Out Tag-Out on page 10.
4. Remove front and rear system panels.
5. At the front of the system, open the dryer module windows to access the
Electrosonic™ airknives.
6. Use a T25 torque head wrench to remove the torque adjusting screw holding
the Electrosonic™ airknife in place.
7. Set the screw aside in a safe place.
Torque Adjust
Mounting Screws
