SUMP PUMP
Sump Pump Installation
2-9317-600-00-0 Aquastorm™ Series Options Guide 17-333
Procedure Use the following steps to connect the sump pump to the Aquastorm™:
1. If your system has been configured with the sump pump, locate and remove
the assembly from the shipment contents.
2. Position the sump pump assembly at the exit end of the system, with the
drain pipe facing the exit end of the Aquastorm™.
3. At the Aquastorm™ exit end, install a customer supplied union or
coupling at the end of the 1½ in. wash, rinse, or wier drain as chosen by the
customer for their specific operation.
4. Install the required length of 1½ in. CPVC drain pipe [not to exceed 610 cm
(20 in.)], to the remaining end of the union or coupling.
5. Connect the opposite end of the drain pipe installed in Step 4. to the 1½ in.
NPTF fitting on the sump.
6. Connect the 1.0 in. NPTF sump outlet to the customer supplied 1.0 in. facility
drain or facility water treatment system.
7. Locate the cable from the sump pump with the connector labeled PG26.
8. Plug the connector labeled PG26 into the receptacle at the exit end of the
Aquastorm™ system labeled PG26.
