Xerox WorkCentre 6605

Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-102
091 402 IOT Drum
Cartridge Kit Life
Pre Warning
Detect Drum Life
Warning
XXXXXXXXXXXXXXXX
IU Kit Life Low
XXXXXXXXXXXXXXXX
Replace Soon
Replace the
Imaging
Unit.
091 911 IOT Waste Toner
Box Life Over
Detect Waste Toner Box
Life Over
Replace
Waste Toner Box
Page 2-200
091 914 IOT K Drum
Comm Fail
Detect Black Drum
Comm Fail
Blk - IU Error
Reseat IU
Error 091-914
Reseat IU
Page 2-201
091 915 DRUM UnitK
CRUM Data
Broken Fail
Wrong data in CRUM of
drum K
Blk - IU Error
Reseat IU
Error 091-915
Reseat IU
Page 2-203
091 917 IOT Y Drum
Comm Fail
Detect Yellow Drum
Comm Fail
Y - IU Error
Reseat IU
Error 091-917
Reseat IU
Page 2-201
091 918 IOT M Drum
Comm Fail
Detect Magenta Drum
Comm Fail
M - IU Error
Reseat IU
Error 091-918
Reseat IU
Page 2-202
091 919 IOT C Drum
Comm Fail
Detect Cyan Drum
Comm Fail
C - IU Error
Reseat IU
Error 091-919
Reseat IU
Page 2-203
091 920 DRUM Y CRUM
Data Broken Fail
Wrong data in CRUM of
drum Y
Y - IU Error
Reseat IU
Error 091-920
Reseat IU
Page 2-204
091 921 IOT K Drum
Detached
Black Insert Black
Imaging Unit
Reinsert the
Black
Imaging
Unit.
091 922 DRUM M CRUM
Data Broken Fail
Wrong data in CRUM of
drum M
M - IU Error
Reseat IU
Error 091-922
Reseat IU
Page 2-204
Phaser 6600 Error Code List
Chain Link Error Error Details Control Panel Messages FIP location
