1. Trial Operation for the Servomotor without a Load
To power
supply
Fig. 202: Trial Operation for Linear Servomotors - Step 1
ð
Ä Chap. 8.4 ‘Trial Operation for the Servomotor without a Load’ page 267
2. Trial Operation with PROFINET Communications
To power
supply
CN1, to host
controller
CN6A, to host
controller
Fig. 203: Trial Operation for Linear Servomotors - Step 2
ð
Ä Chap. 8.5 ‘Trial Operation with PROFINET Communications’ page 272
3. Trial Operation with the Servomotor Connected to the Machine
To power
supply
CN1, to host
controller
CN6A, to host
controller
Fig. 204: Trial Operation for Linear Servomotors - Step 3
ð
Ä Chap. 8.6 ‘Trial Operation with the Servomotor Connected to the Machine’
page 274
Trial Operation
Sigma-7 Series SERVOPACKs
Trial Operation and Actual Operation
Flow of Trial Operation > Flow of Trial Operation for Linear Servomotors
