Preparations
n Confirm the following condition before you adjust the analog monitor output:
The parameters must not be write prohibited.
Applicable Tools
You can use the following tools to adjust analog monitor outputs. The function that is used
is given for each tool.
Offset Adjustment
Tool Function Operating Procedure Ref-
erence
Digital Operator Fn00C
& Σ-7-Series Digital Oper-
ator Operating Manual
(Manual No.: SIEP
S800001 33)
SigmaWin+ Setup - Analog Monitor
Output Adjustment
Ä Operating Procedure for
SigmaWin+, see below
Gain Adjustment
Tool Function Operating Procedure Ref-
erence
Digital Operator Fn00D
& Σ-7-Series Digital Oper-
ator Operating Manual
(Manual No.: SIEP
S800001 33)
SigmaWin+ Setup - Analog Monitor
Output Adjustment
Ä Operating Procedure for
SigmaWin+, see below
Operating Procedure for SigmaWin+
Use the following procedure to adjust the analog monitor output.
1.
Click the
Servo Drive Button in the workspace of the Main Window of the Sig-
maWin+.
2. Select Adjust the Analog Monitor Output in the Menu Dialog Box.
ð
The Adjust the Analog Monitor Output Dialog Box will be displayed.
Sigma-7 Series SERVOPACKs
Monitoring
Monitoring Machine Operation Status and Signal Waveforms > Using the Analog Monitors
