Alarm Code Alarm Name Possible Cause Confirmation Correction Reference
The setting of Pn603
(Regenerative Resist-
ance) is smaller than
the capacity of the
External Regenerative
Resistor.
Check to see if a
Regenerative
Resistor is con-
nected and check
the setting of Pn603.
Correct the setting of
Pn603.
Ä Chap. 6.18
‘Setting the
Regenerative
Resistor
Capacity’
page 194
The external regener-
ative resistance is too
high.
Check the regenera-
tive resistance.
Change the regener-
ative resistance to a
correct value or use
an External Regen-
erative Resistor of an
appropriate capacity.
*2
A failure occurred in
the SERVOPACK.
– The SERVOPACK
may be faulty.
Replace the SERVO-
PACK.
–
A.330
(1330h)
Main Circuit
Power Supply
Wiring Error
(Detected when
the main circuit
power supply is
turned ON.)
The Regenerative
Resistor was discon-
nected when the
SERVOPACK power
supply voltage was
high.
Measure the resist-
ance of the Regener-
ative Resistor using
a measuring instru-
ment.
If you are using the
Regenerative
Resistor built into the
SERVOPACK,
replace the SERVO-
PACK. If you are
using an External
Regenerative
Resistor, replace the
External Regenera-
tive Resistor.
–
DC power was sup-
plied when an AC
power supply input
was specified in the
settings.
Check the power
supply to see if it is a
DC power supply.
Correct the power
supply setting to
match the actual
power supply.
Ä Chap. 6.3
‘Power Supply
Type Settings
for the Main Cir-
cuit and Control
Circuit’
page 142
AC power was sup-
plied when a DC
power supply input
was specified in the
settings.
Check the power
supply to see if it is
an AC power supply.
Correct the power
supply setting to
match the actual
power supply.
Pn600 (2600h)
(Regenerative
Resistor Capacity)
(setting unit: 10 W) is
not set to 0 and an
External Regenerative
Resistor is not con-
nected to one of the
following SERVO-
PACKs: SGD7S-
R70A, -R90A, -1R6A,
-2R8A, -R70F, -R90F,
-2R1F, or - 2R8F.
Check to see if an
External Regenera-
tive Resistor is con-
nected and check
the setting of Pn600
(2600h).
Connect an External
Regenerative
Resistor, or if an
External Regenera-
tive Resistor is not
required, set Pn600
(2600h) to 0.
Ä Chap. 5.4.6
‘Wiring Regen-
erative Resis-
tors’ page 103,
Ä Chap. 6.18
‘Setting the
Regenerative
Resistor
Capacity’
page 194
A failure occurred in
the SERVOPACK.
– The SERVOPACK
may be faulty.
Replace the SERVO-
PACK.
–
Sigma-7 Series SERVOPACKs
Maintenance
Alarm Displays > Troubleshooting Alarms
