Zebra DS9908 Product Reference Guide

Imager Preferences
108
Video Subsampling
Parameter # 667
SSI # F1h 9Bh
This option alters video frame resolution before compression. Multiple pixels are combined to one pixel, resulting in
smaller video frames containing the original content with reduced resolution.
Scan a barcode below to select the desired video subsampling.
Table 11 Video Subsampling
Resolution Value Uncropped Image Size
Full 1280 x 800
1/2 640 x 400
1/4 320 x 200
Full Resolution
(0)
1/2 Resolution
(1)
*1/4 Resolution
(3)

Zebra DS9908 Specifications

General

Sealing	IP52
Scan Technology	Array Imager
Scan Rate	Up to 240 in./610 cm per second
Humidity	5% to 95% RH, non-condensing
Decode Capability	1D, 2D
Connectivity	USB, RS-232, Keyboard Wedge
Image Sensor	1280 x 800
Drop Specification	Multiple 5 ft./1.5 m drops to concrete
Operating Temperature	14°F to 122°F (-10°C to 50°C)
Light Source	LED
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
