Zebra DS9908 Product Reference Guide

Intelligent Document Capture (Hand-held Mode Only)
343
IDC Operating Mode
Parameter Name: DocCap_MODE
Parameter # 594
SSI # F1h 52h
Select the operating mode of the Intelligent Document Capture firmware:
• Off - Disables the IDC feature.
• Anchored - Requires a barcode decode. The image capture region is based off this barcode.
• Free-Form - A printed border or page edge defines the image capture region. A barcode is optional.
• Linked - A printed border or page edge defines the image capture region. A barcode is required.
IDC Zoom Limit Sig_MIN_PERCENT 651 F1h 8Bh 000 353
IDC Maximum Rotation Sig_MAX_ROT 652 F1h 8Ch 00 354
Table 26 Intelligent Document Capture (IDC) Parameter Defaults (Continued)
Parameter Parameter Name
Parameter
Number
1
SSI
Number
2
Default
Page
Number
1. Parameter number decimal values are used for programming via RSM commands.
2. SSI number hex values are used for programming via SSI commands.
*Off
(0)
Anchored
(1)
Free-Form
(2)
Linked
(3)

Zebra DS9908 Specifications

General

Sealing	IP52
Scan Technology	Array Imager
Scan Rate	Up to 240 in./610 cm per second
Humidity	5% to 95% RH, non-condensing
Decode Capability	1D, 2D
Connectivity	USB, RS-232, Keyboard Wedge
Image Sensor	1280 x 800
Drop Specification	Multiple 5 ft./1.5 m drops to concrete
Operating Temperature	14°F to 122°F (-10°C to 50°C)
Light Source	LED
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
