Zebra DS9908 Product Reference Guide

Intelligent Document Capture (Hand-held Mode Only)
350
IDC Maximum Text Length
Parameter Name: DocCap_MAX_TEXT
Parameter # 657
SSI # F1h 91h
Specify the maximum number of characters encoded in a barcode for the IDC firmware to use it as an anchored or
linked barcode. Set this to zero (the default) to disable all checking and use all barcodes.
Scan the following barcode, and then scan two barcodes from Numeric Barcodes in the range of 00 to 55 decimal.
The default is 00.
IDC Captured Image Brighten
Parameter Name: Sig_BRIGHTEN
Parameter # 654
SSI # F1h 8Eh
Enable Captured Image Brighten to make image brightness uniform and enhance contrast such that a large
percent of the background pixels is made completely white (a smaller percent of pixels is made completely black if
the program determines there is no danger of enhancing the contrast of a very bland area).
IDC Maximum Text Length
NOTE: This parameter is also used for Signature Capture.
*Enable Captured Image Brighten
(1)
Disable Captured Image Brighten
(0)

Zebra DS9908 Specifications

General

Sealing	IP52
Scan Technology	Array Imager
Scan Rate	Up to 240 in./610 cm per second
Humidity	5% to 95% RH, non-condensing
Decode Capability	1D, 2D
Connectivity	USB, RS-232, Keyboard Wedge
Image Sensor	1280 x 800
Drop Specification	Multiple 5 ft./1.5 m drops to concrete
Operating Temperature	14°F to 122°F (-10°C to 50°C)
Light Source	LED
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
