Zebra DS9908 Product Reference Guide

Imager Preferences
117
Signature Capture Bits Per Pixel
Parameter # 314
SSI # F0h 3Ah
Scan one of the following barcodes to select the number of significant bits per pixel (BPP) to use when capturing a
signature:
• 1 BPP - For a black and white image.
• 4 BPP - Assigns 1 of 16 levels of grey to each pixel.
• 8 BPP - Assigns 1 of 256 levels of grey to each pixel.
NOTE: The imager ignores these settings for JPEG file formats, which only support 8 BPP.
1 BPP
(0)
4 BPP
(1)
*8 BPP
(2)

Zebra DS9908 Specifications

General

Sealing	IP52
Scan Technology	Array Imager
Scan Rate	Up to 240 in./610 cm per second
Humidity	5% to 95% RH, non-condensing
Decode Capability	1D, 2D
Connectivity	USB, RS-232, Keyboard Wedge
Image Sensor	1280 x 800
Drop Specification	Multiple 5 ft./1.5 m drops to concrete
Operating Temperature	14°F to 122°F (-10°C to 50°C)
Light Source	LED
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
