Zebra DS9908 Product Reference Guide

Symbologies
148
UPC Reduced Quiet Zone
Parameter # 1289
SSI # F8h 05h 09h
Scan one of the following barcodes to enable or disable decoding UPC barcodes with reduced quiet zones (the
margins on either side of the barcode). If you select Enable, select a 1D Quiet Zone Level on page 201.
Code 128
Parameter # 8
SSI # 08h
Scan one of the following barcodes to enable or disable Code 128.
Enable UPC Reduced Quiet Zone
(1)
*Disable UPC Reduced Quiet Zone
(0)
*Enable Code 128
(1)
Disable Code 128
(0)

Zebra DS9908 Specifications

General

Sealing	IP52
Scan Technology	Array Imager
Scan Rate	Up to 240 in./610 cm per second
Humidity	5% to 95% RH, non-condensing
Decode Capability	1D, 2D
Connectivity	USB, RS-232, Keyboard Wedge
Image Sensor	1280 x 800
Drop Specification	Multiple 5 ft./1.5 m drops to concrete
Operating Temperature	14°F to 122°F (-10°C to 50°C)
Light Source	LED
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
