RS-232 Interface
271
If problems occur with the system, see Troubleshooting on page 48.
RS-232 Parameter Defaults
Table 19 lists defaults for RS-232 host parameters. Change these values in one of two ways:
• Scan the appropriate barcodes in this chapter. The new value replaces the standard default value in
memory. To recall default parameter values, see Default Parameters on page 59.
• Configure the scanner using the 123Scan
configuration program. See 123Scan and Software Tools.
NOTE: See Parameter Defaults for all user preference, host, symbology, and miscellaneous default parameters.
Table 19 RS-232 Interface Parameter Defaults
Parameter Default
Page
Number
RS-232 Host Parameters
RS-232 Host Types Standard 274
Baud Rate 9600 276
Parity None 277
Stop Bits 1 Stop Bit 277
Data Bits 8-bit 278
Check Receive Errors Enable 278
Hardware Handshaking None 279
Software Handshaking None 281
Host Serial Response Timeout 2 Seconds 283
RTS Line State Low RTS 284
Beep on <BEL> Disable 284
Intercharacter Delay 0 msec 285
Nixdorf Beep/LED Options Normal Operation 286
Barcodes with Unknown Characters Send Barcode With Unknown
Characters
286
