Symbologies
213
GS1 QR
Parameter # 1343
SSI # F8h 05h 3Fh
Scan one of the following barcodes
to enable or disable GS1 QR.
MicroQR
Parameter # 573
SSI # F1h 3Dh
Scan one of the following barcodes
to en
able or d
isable MicroQR
.
*
Enable GS1
QR
(1)
Disable GS1 QR
(0)
*
Enable MicroQR
(1)
Disable MicroQR
(0)
212
214
