Zebra DS9908 Product Reference Guide

Keyboard Wedge Interface
300
Simulated Caps Lock
Scan Enable Caps Lock to invert upper and lower case characters on the barcode as if the Caps Lock state is
enabled on the keyboard. This inversion occurs regardless of the keyboard’s Caps Lock state. Note that this only
applies to alpha characters.
NOTES: - Simulated Caps Lock applies to ASCII characters only.
- Do not enable this parameter if either of the following parameters are enabled:
Convert to Upper Case on page 301
Convert to Lower Case on page 301
Enable Caps Lock
*Disable Caps Lock

Zebra DS9908 Specifications

General

Sealing	IP52
Scan Technology	Array Imager
Scan Rate	Up to 240 in./610 cm per second
Humidity	5% to 95% RH, non-condensing
Decode Capability	1D, 2D
Connectivity	USB, RS-232, Keyboard Wedge
Image Sensor	1280 x 800
Drop Specification	Multiple 5 ft./1.5 m drops to concrete
Operating Temperature	14°F to 122°F (-10°C to 50°C)
Light Source	LED
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
