Zebra DS9908 Product Reference Guide

Symbologies
203
Composite CC-A/B
Parameter # 342
SSI # F0h 56h
Scan one of the following barcodes to enable or disable Composite barcodes of type CC-A/B.
Composite TLC-39
Parameter # 371
SSI # F0h 73h
Scan one of the following barcodes to enable or disable Composite barcodes of type TLC-39.
NOTE: The default value is based on model type: The default for SR/DL models is disable; The default for HD/HL
models is enable.
*Enable CC-A/B
(1)
(Default - HD/HL Models)
*Disable CC-A/B
(0)
(Default - SR/DL Models)
Enable TLC39
(1)
*Disable TLC39
(0)

Zebra DS9908 Specifications

General

Sealing	IP52
Scan Technology	Array Imager
Scan Rate	Up to 240 in./610 cm per second
Humidity	5% to 95% RH, non-condensing
Decode Capability	1D, 2D
Connectivity	USB, RS-232, Keyboard Wedge
Image Sensor	1280 x 800
Drop Specification	Multiple 5 ft./1.5 m drops to concrete
Operating Temperature	14°F to 122°F (-10°C to 50°C)
Light Source	LED
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
