Zebra DS9908

To Next Page

To Previous Page

456

Programming Reference

Symbol Code Identifiers

Table 37 Symbol Code Characters

Code Character Code Type

A UPC-A, UPC-E, UPC-E1, EAN-8, EAN-13

B Code 39, Code 32

C Codabar

Code 128, ISBT 128, ISBT 128 Concatenated

E Code 93

F Interleaved 2 of 5

G Discrete 2 of 5, or Discrete 2 of 5 IATA

H Code 11

JMSI

KGS1-128

L Bookland EAN

M Trioptic Code 39

N Coupon Code

R GS1 DataBar Family

S Matrix 2 of 5

T UCC Composite, TLC 39

U Chinese 2 of 5

V Korean 3 of 5

ISSN EAN

, PDF417, Macro PDF417, Micro PDF417

z Aztec, Aztec Rune

P00 Data Matrix
