Zebra DS9908 Product Reference Guide

Intelligent Document Capture (Hand-held Mode Only)
344
IDC Symbology
Parameter Name: DocCap_SYMBOLOGY
Parameter # 655
SSI # F1h 8Fh
Select the barcode type(s) to use when Document Capture mode is not set to Off. To enable more than one
symbology at a time, simply add the values together. For example, to enable PDF417, Data Matrix, and Code 39
write a value of 98 (32 + 64 + 2).
Scan the following barcode, and then scan three barcodes from Numeric Barcodes in the range of 001 to 511
decimal. The default is 001.
Table 27 IDC Symbologies
Symbology Value (Decimal)
Code 128 1
Code 39 2
I 2 of 5 4
D 2 of 5 8
Codabar 16
PD 417 32
Data Matrix 64
EAN 128 128
Aztec 256
IDC Symbology
