Zebra DS9908 Product Reference Guide

Intelligent Document Capture (Hand-held Mode Only)
348
IDC Bits Per Pixel
Parameter Name: DocCap_BPP
Parameter # 602
SSI # F1h 5Ah
Select the number of significant bits per pixel (BPP) to use when capturing an image. Select 1 BPP for a black and
white image, 4 BPP to assign 1 of 16 levels of grey to each pixel, or 8 BPP to assign 1 of 256 levels of grey to each
pixel.
IDC JPEG Quality
Parameter Name: DocCap_JPEG_Qual
Parameter # 603
SSI # F1h 5Bh
Set the amount of JPEG compression to perform on the captured image. Higher numbers produce a better quality
image but larger files.
Scan the following barcode, and then scan three barcodes from Numeric Barcodes in the range of 005 to 100
decimal. The default is 065.
NOTE: The scanner ignores these settings for JPEG file formats, which only support 8 BPP.
1 BPP
(0)
4 BPP
(1)
*8 BPP
(2)
IDC JPEG Quality

Zebra DS9908 Specifications

General

Sealing	IP52
Scan Technology	Array Imager
Scan Rate	Up to 240 in./610 cm per second
Humidity	5% to 95% RH, non-condensing
Decode Capability	1D, 2D
Connectivity	USB, RS-232, Keyboard Wedge
Image Sensor	1280 x 800
Drop Specification	Multiple 5 ft./1.5 m drops to concrete
Operating Temperature	14°F to 122°F (-10°C to 50°C)
Light Source	LED
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
