IBM Interface
293
RS-485 Barcode Configuration Directive
The IBM RS-485 host can enable and disable code types. Scan Ignore Barcode Configuration Directive to
prevent the scanner from processing the host request. All directives are still acknowledged to the IBM RS-485 host
as if they were processed.
IBM-485 Specification Version
Parameter # 1729 (SSI # F8h 06h C1h)
The IBM interface specification version selected defines how code types are reported over the IBM interface.
When you scan Original Specification, only Symbologies that were historically supported on each individual port
are reported as known. When you scan Version 2.0, all Symbologies covered in the newer IBM specification are
reported as known with their respective code types.
Honor Barcode Configuration Directive
*Ignore Barcode Configuration Directive
*Original Specification
(0)
Version 2.0
(1)
To Next Page
