Zebra DS9908 Product Reference Guide

Intelligent Document Capture (Hand-held Mode Only)
347
IDC Aspect
Parameter Name: DocCap_ASPECT
Parameter # 595
SSI # F1h 53h
This parameter only applies when IDC Operating Mode is set to Anchored. Specify the barcode's aspect ratio of a
thin bar or space. The barcode's height is divided by this value to obtain the unit in the y-axis. Set this parameter to
zero to calculate the aspect value automatically.
Scan the following barcode, and then scan three barcodes from Numeric Barcodes in the range of 000 to 255. The
default is 000.
IDC File Format Selector
Parameter Name: DocCap_FMT
Parameter # 601
SSI # F1h 59h
Select a document capture file format appropriate for your system (BMP, TIFF, or JPEG). The scanner stores
captured areas in the selected format.
IDC Aspect
*JPEG
(1)
BMP
(3)
TIFF
(4)

Zebra DS9908 Specifications

General

Sealing	IP52
Scan Technology	Array Imager
Scan Rate	Up to 240 in./610 cm per second
Humidity	5% to 95% RH, non-condensing
Decode Capability	1D, 2D
Connectivity	USB, RS-232, Keyboard Wedge
Image Sensor	1280 x 800
Drop Specification	Multiple 5 ft./1.5 m drops to concrete
Operating Temperature	14°F to 122°F (-10°C to 50°C)
Light Source	LED
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
