Zebra DS9908 Product Reference Guide

28
Getting Started
Introduction
The Zebra DS9908 is the newest generation premium hybrid hand-held/hands-free imager.
The DS9908 combines superior 1D and 2D barcode scanning with advanced imaging applications in a light-weight,
hands-free/hand-held design. Its unique design offers the performance of a hands-free presentation scanner and
the flexibility of a hand-held. The DS9908 automatically switches between hands-free and hand-held modes
seamlessly accommodating both presentation and hand-held triggered operation.
Figure 1 DS9908 Scanner

Zebra DS9908 Specifications

General

Sealing	IP52
Scan Technology	Array Imager
Scan Rate	Up to 240 in./610 cm per second
Humidity	5% to 95% RH, non-condensing
Decode Capability	1D, 2D
Connectivity	USB, RS-232, Keyboard Wedge
Image Sensor	1280 x 800
Drop Specification	Multiple 5 ft./1.5 m drops to concrete
Operating Temperature	14°F to 122°F (-10°C to 50°C)
Light Source	LED
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
