Zebra DS9908 Product Reference Guide

Symbologies
214
Linked QR Mode
Parameter # 1847
SSI # 737h
Scan one of the following barcodes to select a linked QR mode.
• Linked QR Only - Does not decode individual QRs from a set of linked QR codes.
• Individual QR With Headers - Decodes individual QRs from a set of linked QR codes and keeps the
header information and data.
• Individual QR No Headers - Decodes individual QRs from a set of linked QR codes and just transmits
data without header information.
* Linked QR Only
(0)
Individual QR With Headers
(1)
Individual QR No Headers
(2)

Zebra DS9908 Specifications

General

Sealing	IP52
Scan Technology	Array Imager
Scan Rate	Up to 240 in./610 cm per second
Humidity	5% to 95% RH, non-condensing
Decode Capability	1D, 2D
Connectivity	USB, RS-232, Keyboard Wedge
Image Sensor	1280 x 800
Drop Specification	Multiple 5 ft./1.5 m drops to concrete
Operating Temperature	14°F to 122°F (-10°C to 50°C)
Light Source	LED
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
