Zebra DS9908 Product Reference Guide

Imager Preferences
115
Signature Capture
Parameter # 93
SSI # 5Dh
A signature capture barcode is a special-purpose symbology which delineates a signature capture area in a
document with a machine-readable format. The recognition pattern is variable so it can optionally provide an index
to various signatures. The region inside the barcode pattern is considered the signature capture area. See
Signature Capture for more information.
Output File Format
Decoding a signature capture barcode de-skews the signature image and converts the image to a BMP, JPEG, or
TIFF file format. The output data includes the file descriptor followed by the formatted signature image.
Scan one of the following barcodes to enable or disable Signature Capture.
Table 12 Output File Format
File Descriptor
Signature Image
Output Format
(1 byte)
Signature Type (1 byte)
Signature Image Size
(4 bytes)
(BIG Endian)
JPEG - 1
BMP - 3
TIFF - 4
1-8 0x00000400 0x00010203….
Enable Signature Capture
(1)
*Disable Signature Capture
(0)

Zebra DS9908 Specifications

General

Sealing	IP52
Scan Technology	Array Imager
Scan Rate	Up to 240 in./610 cm per second
Humidity	5% to 95% RH, non-condensing
Decode Capability	1D, 2D
Connectivity	USB, RS-232, Keyboard Wedge
Image Sensor	1280 x 800
Drop Specification	Multiple 5 ft./1.5 m drops to concrete
Operating Temperature	14°F to 122°F (-10°C to 50°C)
Light Source	LED
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
