Zebra DS9908 Product Reference Guide

Intelligent Document Capture (Hand-held Mode Only)
346
IDC Width
Parameter Name: DocCap_WIDTH
Parameter # 598
SSI # F1h 56h
This parameter only applies when IDC Operating Mode is set to Anchored. Specify the width of the region to
capture.
Scan the following barcode, and then scan four barcodes from Numeric Barcodes in the range of 0000 to 1279.
The default is 0300.
IDC Height
Parameter Name: DocCap_HEIGHT
Parameter # 599
SSI # F1h 57h
This parameter only applies when IDC Operating Mode is set to Anchored. Specify the height of the region to
capture.
Scan the following barcode, and then scan four barcodes from Numeric Barcodes in the range of 0000 to 1279.
The default is 0050.
IDC Width
IDC Height
