Zebra DS9908 Product Reference Guide

Keyboard Wedge Interface
296
Keyboard Wedge Parameter Defaults
Table 23 lists defaults for keyboard wedge host parameters. Change these values in one of two ways:
• Scan the appropriate barcodes in this chapter. The new value replaces the standard default value in
memory. To recall default parameter values, see Default Parameters on page 59.
• Configure the scanner using the 123Scan configuration program. See 123Scan and Software Tools.
NOTE: See Parameter Defaults for all user preference, host, symbology, and miscellaneous default parameters.
Table 23 Keyboard Wedge Interface Parameter Defaults
Parameter Default
Page
Number
Keyboard Wedge Host Parameters
Keyboard Wedge Host Type IBM AT Notebook 297
Barcodes with Unknown Characters Send Barcodes with Unknown
Characters
297
Keystroke Delay No Delay 298
Intra-keystroke Delay Disable 298
Alternate Numeric Keypad Emulation Enable 299
Quick Keypad Emulation Enable 299
Simulated Caps Lock Disable 300
Caps Lock Override Disable 301
Convert Case Do Not Convert 301
Function Key Mapping Disable 302
FN1 Substitution Disable 302
Send Make and Break Send Make and Break Scan
Codes
303

Zebra DS9908 Specifications

General

Sealing	IP52
Scan Technology	Array Imager
Scan Rate	Up to 240 in./610 cm per second
Humidity	5% to 95% RH, non-condensing
Decode Capability	1D, 2D
Connectivity	USB, RS-232, Keyboard Wedge
Image Sensor	1280 x 800
Drop Specification	Multiple 5 ft./1.5 m drops to concrete
Operating Temperature	14°F to 122°F (-10°C to 50°C)
Light Source	LED
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
