Zebra DS9908 Product Reference Guide

Symbologies
155
Code 128 Reduced Quiet Zone
Parameter # 1208
SSI # F8h 04h B8h
Scan one of the following barcodes to enable or disable decoding Code 128 barcodes with reduced quiet zones
(the margins on either side of the barcode). If you select Enable, select a 1D Quiet Zone Level on page 201.
Code 39
Parameter # 0
SSI # 00h
Scan one of the following barcodes to enable or disable Code 39.
Enable Code 128 Reduced Quiet Zone
(1)
*Disable Code 128 Reduced Quiet Zone
(0)
*Enable Code 39
(1)
Disable Code 39
(0)

Zebra DS9908 Specifications

General

Sealing	IP52
Scan Technology	Array Imager
Scan Rate	Up to 240 in./610 cm per second
Humidity	5% to 95% RH, non-condensing
Decode Capability	1D, 2D
Connectivity	USB, RS-232, Keyboard Wedge
Image Sensor	1280 x 800
Drop Specification	Multiple 5 ft./1.5 m drops to concrete
Operating Temperature	14°F to 122°F (-10°C to 50°C)
Light Source	LED
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
