Zebra DS9908 Product Reference Guide

Intelligent Document Capture (Hand-held Mode Only)
342
Image Document Capture Parameter Defaults
Table 26 lists defaults for IDC parameters. Change these values in one of two ways:
• Scan the appropriate barcodes in this chapter. The new value replaces the standard default value in
memory. To recall default parameter values, see Default Parameters on page 59.
• Configure the scanner using the 123Scan configuration program. See 123Scan and Software Tools.
Alternatively, use the sample application to set parameters using the parameter name. The application provides
prompts and error checking to assist in setting the parameters correctly and easily. You must use an application to
set a parameter to a negative value, as the IDC X Coordinate can require.
NOTE: See Parameter Defaults for all user preference, host, symbology, and miscellaneous default
parameters.
Table 26 Intelligent Document Capture (IDC) Parameter Defaults
Parameter Parameter Name
Parameter
Number
1
SSI
Number
2
Default
Page
Number
Intelligent Document Capture (IDC) Parameters
IDC Operating Mode DocCap_MODE 594 F1h 52h Off 343
IDC Symbology DocCap_SYMBOLOGY 655 F1h 8Fh 001 344
IDC X Coordinate DocCap_X 596 F4h F1h 54h -151 345
IDC Y Coordinate DocCap_Y 597 F4h F1h 55h -050 345
IDC Width DocCap_WIDTH 598 F1h 56h 0300 346
IDC Height DocCap_HEIGHT 599 F1h 57h 0050 346
IDC Aspect DocCap_ASPECT 595 F1h 53h 000 347
IDC File Format Selector DocCap_FMT 601 F1h 59h JPEG 347
IDC Bits Per Pixel DocCap_BPP 602 F1h 5Ah 8 BPP 348
IDC JPEG Quality DocCap_JPEG_Qual 603 F1h 5Bh 065 348
IDC Find Box Outline Sig_FINDBOX 727 F1h D7h Disable 349
IDC Minimum Text Length DocCap_MIN_TEXT 656 F1h 90h 00 349
IDC Maximum Text Length DocCap_MAX_TEXT 657 F1h 91h 00 350
IDC Captured Image Brighten Sig_BRIGHTEN 654 F1h 8Eh Enable 350
IDC Captured Image Sharpen Sig_SHARPEN 658 F1h 92h Enable 351
IDC Border Type DocCap_BORDER 829 F2h 3Dh None 352
IDC Delay Time DocCap_DELAY 830 F2h 3Eh 000 353
1. Parameter number decimal values are used for programming via RSM commands.
2. SSI number hex values are used for programming via SSI commands.

Zebra DS9908 Specifications

General

Sealing	IP52
Scan Technology	Array Imager
Scan Rate	Up to 240 in./610 cm per second
Humidity	5% to 95% RH, non-condensing
Decode Capability	1D, 2D
Connectivity	USB, RS-232, Keyboard Wedge
Image Sensor	1280 x 800
Drop Specification	Multiple 5 ft./1.5 m drops to concrete
Operating Temperature	14°F to 122°F (-10°C to 50°C)
Light Source	LED
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
