Zebra DS9908 Product Reference Guide

Driver’s License Set Up (DS9908-DL/HL)
398
Parsing Rule Example
Scan the following barcodes in sequence to program the scanner to extract and transmit first, middle, and last
names; mailing address line 1; mailing address line 2; mailing address city; mailing address state; mailing address
postal code; and, date of birth. Then, scan a driver’s license barcode.
Keyboard Characters (continued)
Send Tab Key
Send Enter Key
NOTE: This example applies to RS-232. To use this example with a USB interface, enable Function Key
Mapping on page 239 to send the Enter key properly.
1
Embedded Driver’s License Parsing
2
Begin New Driver’s License Parse Rule
3
First Name

Zebra DS9908 Specifications

General

Sealing	IP52
Scan Technology	Array Imager
Scan Rate	Up to 240 in./610 cm per second
Humidity	5% to 95% RH, non-condensing
Decode Capability	1D, 2D
Connectivity	USB, RS-232, Keyboard Wedge
Image Sensor	1280 x 800
Drop Specification	Multiple 5 ft./1.5 m drops to concrete
Operating Temperature	14°F to 122°F (-10°C to 50°C)
Light Source	LED
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
