Zebra DS9908 Product Reference Guide

Getting Started
35
Mounting on a Wall
To mount the DS9908 on a wall:
1. Place the bracket in its desired location on the wall and insert three #6 screws (not included) through each
screw hole in the bracket.
Figure 8 Installing the Multi-Mount Bracket
2. Tighten the screws to secure the bracket to the wall.
3. Slide the base of the scanner into the bracket, oriented so the scan window faces down (Figure 9).
Figure 9 Insert the Scanner

Zebra DS9908 Specifications

General

Sealing	IP52
Scan Technology	Array Imager
Scan Rate	Up to 240 in./610 cm per second
Humidity	5% to 95% RH, non-condensing
Decode Capability	1D, 2D
Connectivity	USB, RS-232, Keyboard Wedge
Image Sensor	1280 x 800
Drop Specification	Multiple 5 ft./1.5 m drops to concrete
Operating Temperature	14°F to 122°F (-10°C to 50°C)
Light Source	LED
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
