Zebra DS9908 Product Reference Guide

Intelligent Document Capture (Hand-held Mode Only)
349
IDC Find Box Outline
Parameter Name: Sig_FINDBOX
Parameter # 727
SSI # F1h D7h
This parameter only applies when IDC Operating Mode is set to Anchored. Scan Enable Find Box Outline to
search for a rectangular border during document capture.
IDC Minimum Text Length
Parameter Name: DocCap_MIN_TEXT
Parameter # 656
SSI # F1h 90h
Specify the minimum number of characters encoded in a barcode for the IDC firmware to use it as an anchored or
linked barcode. Set this to zero (the default) to disable all checking and use all barcodes.
Scan the following barcode, and then scan two barcodes from Numeric Barcodes in the range of 00 to 55 decimal.
The default is 00.
Enable Find Box Outline
(1)
*Disable Find Box Outline
(0)
IDC Minimum Text Length

Zebra DS9908 Specifications

General

Sealing	IP52
Scan Technology	Array Imager
Scan Rate	Up to 240 in./610 cm per second
Humidity	5% to 95% RH, non-condensing
Decode Capability	1D, 2D
Connectivity	USB, RS-232, Keyboard Wedge
Image Sensor	1280 x 800
Drop Specification	Multiple 5 ft./1.5 m drops to concrete
Operating Temperature	14°F to 122°F (-10°C to 50°C)
Light Source	LED
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
