Maintenance, Troubleshooting, and Technical Specifications
52
Technical Specifications
Table 6 Technical Specifications
Item Description
Physical Characteristics
Dimensions (SR, DL, and HD models) 8 in. (max) H x 5.2 in. L x 3.7 in. W
20.3 cm (max) H x 13.2 cm L x 9.4 cm W
Weight (SR, DL, and HD models) 11.6 oz.
330 g
Available Colors
Midnight Black (SR/DL model only), Alpine White (HD/HL model
only)
Supported Host Interfaces USB, RS232, Keyboard Wedge, TGCS (IBM) 46XX over RS485
Keyboard Support Supports over 90 international keyboards
User Indicators Direct Decode Indicator, Good Decode LEDs, Rear View LEDs,
Speaker (Adjustable Tone & Volume), Hand-held Touch Zones
Electrical Characteristics
SR and DL Models
Minimum Typical Maximum Unit
Supply Voltage 4.5 5.0 5.5 V
Idle current (Hand-held) 70 mA
Idle current (Hands-free) 132 mA
Scanning current (Hand-held) 321 mA
Scanning current (Hands-free) 297 mA
HD Models
Minimum Typical Maximum Unit
Supply Voltage 4.5 5.0 5.5 V
Idle current (Hand-held) 70 mA
